Interfaces

Especificações Técnicas

• CPU

  Intel® Processor N100 (Alder Lake-N)

  – Total Cores: 4

  – Total Threads: 4

  – Max Turbo Frequency: 3.40 GHz

  – Cache: 6 MB Intel® Smart Cache

  – Intel® Gaussian & Neural Accelerator 3.0

  – Intel® Image Processing Unit 6.0

  – Support for Intel® Virtualization Technology

• GPU

  – Intel® UHD Graphics

  – Graphics Max Dynamic Frequency: 750 MHz

  – DirectX Support: 12.1

  – OpenGL Support: 4.6

  – OpenCL Support: 3.0

• RAM

  LPDDR5 RAM

  Maximum Frequency of 4800 MT/s

  – 4GB

  – 8GB

  – 12GB

  – 16GB

• Storage

  Optional Onboard eMMC

  SPI Flash for BIOS

  1x M.2 M Key Connector with PCIe 3.0 4-lane for M.2 2230 NVMe SSD

• Display

  Dual Display Outputs via Two Micro HDMI up to 4Kp60

• Ethernet

  1x 2.5G Ethernet Port with PoE Support(Additional PoE HAT Required)

  Wireless Connectivity

  – IEEE 802.11 a/b/g/n/ac/ax (WiFi 6) and Bluetooth 5.2 with BLE

  – IEEE 802.11 a/b/g/n/ac (WiFi 5) and Bluetooth 5.0 with BLE

• USB

  1x USB 2.0 HOST Type A Port

  3x USB 3.0 HOST Type A Ports

• Audio

  1x Headphone Jack with Microphone Input

• Connectivity

  1x RTC Battery Socket

  1x 2-Pin Fan Header

  1x 2-Pin Power Input Header

  40-Pin Color GPIO Header

  – Up to 2x SPI

  – Up to 2x UART

  – Up to 2x I2C

  – Up to 16x PWM

  – Up to 8x PIO(Programmable IO)

  – 2 x 5V DC power out

  – 2 x 3.3V power out

• Button

  1x Power Button is used for powering on and off

  1x BOOTSEL Button is used to put the RP2040 into USB mass storage mode for firmware upload.

• Software

  Windows 10 / 11

  Debian / Ubuntu Linux support

• Power_Requirements

  The Radxa X4 supports the following power input:

  – USB Type-C PD Version 2.0 with 12V/2.5A.

  The recommended power source should be able to produce, at least, 18W without power consuming devices on USB 3 or 25W with full USB ports load.

• Operating_Conditions

  Recommended environmental temperature: 0 ~ 50°C

• Dimension

  85 mm x 56 mm
