Interfaces

Especificações Técnicas

• SoC

  Rockchip RK3588

• CPU

  Quad Cortex®-A76 @ 2.2~2.4GHz and a Quad Cortex®-A55 @ 1.8GHz

• GPU

  Arm® Mali™ G610MC4

  – OpenGL® ES1.1, ES2.0, and ES3.2

  – OpenCL® 1.1, 1.2 and 2.2

  – Vulkan® 1.1 and 1.2

  – Embedded high performance 2D image acceleration module

• NPU

  Supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration

  Computing power is up to 6TOPs

• Multimedia

  H.265 / H.264 / AV1 / AVS2 multivideo decoder up to 8K@60fps

  H.264 / H.265 multivideo encoder up to 8K@30fps

• RAM

  64bit LPDDR5

  – 4GB

  – 8GB

  – 16GB

  – 24GB

  – 32GB

• Storage

  1x SPI Flash for Bootloader

  1x Optional Onboard eMMC

  1x microSD Card Slot

  2x M.2 M Key Connector each with PCIe 3.0 2-lane

• Audio

  1x 4‐ring 3.5mm Headphone Jack with Microphone Input

• Display

  1x Standard HDMI 2.1 supporting up to 8Kp60

  1x Standard HDMI 2.1 supporting up to 4Kp60

  1x DP supporting up to 4Kp60 via USB Type C port

  1x 4-lane MIPI DSI supporting up to 1080p60

  Supports Simultaneous Output of 4 Displays: 4K + 4K + 4K + 2K Resolutions

  Supports Simultaneous Output of 3 Displays: 8K + 4K + 2K Resolutions

• Video_Input

  1x Standard HDMI Input supporting up to 4Kp60

  2x 4-lane or 4x 2-lane MIPI CSI for camera

• USB

  1x USB Type-C™ port

  – DP display up to 4Kp60

  – USB 3.1 Gen1 OTG

  2x USB 3.1 Gen1 Type A HOST port

  2x USB 2.0 Type A HOST port

• Ethernet

  1x 2.5 Gigabit Ethernet port with PoE support(Additional PoE HAT Required)

• Wireless

  Onboard WiFi 6 & BT 5.2 with Dual Antenna Connector

• Mobile_Network

  1x M.2 B Key Connector

  Standard M.2 3042 B Key modules are supported.

  1x SIM Card Socket

• Miscellaneous

  1x RTC battery connector

  1x PWM fan connector

  1x Power button

  1x Recovery button

  1x RGB LED for power indicator, system status indicator and custom usage

• Power_Requirements

  USB Type-C™ PD Version 2.0 with 9V/2A, 12V/2A, 15V/2A and 20V/2A

  Power adapter with fixed voltage in 5.2V to 20V range on the USB Type-C port

  5V Power applied to the GPIO PIN 2 & 4

• Software

  Radxa OS

  Android

• Operating Conditions

  Recommended environmental temperature: 0 ~ 50°C

  Radxa ROCK 5B has a temperature limit of 80°C, beyond which it throttles clock speeds for reliability

  For continuous high-performance use, external cooling methods like heat sinks or fans can maintain maximum clock speed below the 80°C limit

• Dimension

  100 mm x 75 mm

• Compliance Certification

  FCC / CE
