Interfaces

Especificações Técnicas

• SoC

  Rockchip RK3588

• CPU

  Quad Cortex®-A76 @ 2.2~2.4GHz and a Quad Cortex®-A55 @ 1.8GHz

• GPU

  Arm® Mali™ G610MC4

  – OpenGL® ES1.1, ES2.0, and ES3.2

  – OpenCL® 1.1, 1.2 and 2.2

  – Vulkan® 1.1 and 1.2

  – Embedded high performance 2D image acceleration module

• NPU

  Supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration

  Computing power is up to 6TOPs

• RAM

  64bit LPDDR4x

  – 4GB

  – 8GB

  – 16GB

  – 32GB

• Storage

  SPI Flash: SPI Flash for Bootloader

  eMMC Connector: Support high performance eMMC module up to 512GB

  Micro SD Card Slot: Support microSD cards with SDHC / SDXC / UHS-I speed

  M.2 M Key Connector: Support 2280 NVMe SSD(4-lane PCIe 3.0)

• Audio

  1x 4‐ring 3.5mm Headphone Jack with mic input

• Display

  1x Standard HDMI 2.1 supporting up to 8Kp60

  1x Standard HDMI 2.1 supporting up to 4Kp60

  1x DP via USB Type C port

  1x MIPI DSI supporting up to 1080p60

  Able to provide 4 display outputs at the same time

• Video Input

  1x Micro HDMI Input supporting up to 4Kp60

• Camera

  1x 4-lane or 2x 2-lane MIPI CSI for camera up to 48M

• Multimedia

  H.265 / H.264 / AV1 / AVS2 multivideo decoder up to 8K@60fps

  H.264 / H.265 multivideo decoder up to 8K@30fps

• USB

  1x Full function USB Type-C™ port

  – Supporting PD Version 2.0

  – DP display up to 4Kp60

  – USB 3.1 Gen1

  1x USB 3.1 Gen1 Type A HOST port

  1x USB 3.1 Gen1 Type A HOST port

  2x USB 2.0 Type A HOST port

• Ethernet

  1x 2.5 Gigabit Ethernet port (supports PoE with add-on PoE HAT)

• Wireless

  Support Standard M.2 WiFi 6(E) / BT 5 module

  Support Radxa Wireless Module A8

• Miscellaneous

  1x RTC battery connector

  1x PWM fan connector

  1x Power button

  1x Recovery button

  1x RGB LED for power indicator, system status indicator and custom usage

• Power Requirements

  USB Type-C™ PD Version 2.0 with 9V/2A, 12V/2A, 15V/2A and 20V/2A

  Power adapter with fixed voltage in 5.2V to 20V range on the USB Type-C port

  5V Power applied to the GPIO PIN 2 & 4

• Software

  Radxa OS

  Android

  Various third-party images

  For more information click on Downloads

• Operating Conditions

  Recommended environmental temperature: 0 ~ 50°C

  Radxa ROCK 5B has a temperature limit of 80°C, beyond which it throttles clock speeds for reliability

  For continuous high-performance use, external cooling methods like heat sinks or fans can maintain maximum clock speed below the 80°C limit

• Dimension

  100 mm x 75 mm

• Compliance Certification

  FCC / CE
