Interfaces

Especificações Técnicas

• SoC

  Rockchip RK3588

• CPU

  Quad Cortex®-A76 @ 2.2~2.4GHz and a Quad Cortex®-A55 @ 1.8GHz

• GPU

  Arm® Mali™ G610MC4

  – OpenGL® ES1.1, ES2.0, and ES3.2

  – OpenCL® 1.1, 1.2 and 2.2

  – Vulkan® 1.1 and 1.2

  – Embedded high performance 2D image acceleration module

• NPU

  Supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration

  Computing power is up to 6TOPs

• RAM

  LPDDR5

  – 4GB

  – 8GB

  – 16GB

  – 32GB

• Multimedia

  H.265 / VP9 / AVS2 multivideo decoder up to 8K@60fps

  H.264 multivideo decoder up to 8K@30fps

  H.265 / H.264 multivideo encoder up to 8K@30fps

• Storage

  1x Onboard eMMC for ROOBI OS

  1x microSD Card Slot

  2x M.2 M Key Connector for M.2 NVMe SSD(PCIe 3.0 2-lane)

  1x SPI Flash for Bootloader

• Audio

  1x Headphone Jack

  1x Microphone Jack

  1x Front Audio header

  1x S/PDIF

• Video Output

  2x Standard HDMI, one supporting up to 8Kp60, one supporting up to 4Kp60

  1x DP up to 4Kp60 via USB Type-C Port

  2x 4-lane MIPI DSI for MIPI LCD

  1x eDP with Touch Panel support

  Able to provide 4 display outputs at the same time

• Video Input

  1x HDMI Input up to 4Kp60

  2x 4‑lane MIPI CSI or 4x 2‑lane MIPI CSI

• USB

  2x USB 2.0 Type-A HOST Ports

  4x USB 3.0 Type-A HOST Ports

  1x USB 3.0 OTG / HOST Type-C Port

  2x USB 2.0 Interface via Front USB header

• Ethernet

  2x 2.5G Ethernet Ports both with PoE support(Additional PoE Module Required)

• Wireless

  1x M.2 E Key Connector for WiFi 6

• Other

  1x PWM fan connector

  1x RTC Socket(CR1220 battery)

  1x Front Panel header for Power Button / Reset Button / Status LED

• Power

  1x 12V DC Power Jack(55x25mm)

  1x Standard 24-Pin ATX Power Supply Interface

  1x PoE Header(Additional PoE Module Required)

• Operating System

  Radxa OS / Debian / Android

• Operating Conditions

  Recommended environmental temperature: 0 ~ 50°C

  Radxa ROCK 5 ITX+ has a temperature limit of 80°C, beyond which it throttles clock speeds for reliability

  For continuous high-performance use, external cooling methods like heat sinks or fans can maintain maximum clock speed below the 80°C limit

• Dimension

  170 mm x 170 mm

• Compliance

  FCC / CE
