Interfaces

Especificações Técnicas

• SoC

  Rockchip RK3399‑T

• CPU

  Dual-Core Arm® Cortex-A72 @ 1.5GHz and Quad-Core Arm® Cortex-A53 @ 1.0GHz

• GPU

  Arm Mali™ T860MP4 GPU, supporting

  – OpenGL® ES 1.1 / 2.0 / 3.0 / 3.1 / 3.2

  – Vulkan® 1.0

  – OpenCL® 1.1 / 1.2

  – DirectX® 11.1

• Multimedia

  H.265/VP9 (HEVC) hardware decode (up to 4Kp60)

  H.264 hardware decode (up to 1080p60)

• RAM

  LPDDR4

  – 4GB

• Storage

  1x eMMC B2B connector

  1x Micro SD Card Slot

• Display

  2x Micro HDMI ports support displays up to 4Kp60 resolution and 2Kp60

  1x MIPI DSI interface supports 1080p@60fps

• Camera

  1x 2-lane MIPI CSI

• Wireless

  – 802.11 b/g/n/ac (WiFi 5) Wireless LAN

  – Bluetooth 5.0 with BLE

• Ethernet

  1x Gigabit Ethernet with Power over Ethernet (PoE) support, powered by PoE with an additional HAT required

• USB

  1x USB3 OTG/HOST port

  1x USB3 HOST port

  2x USB2 HOST ports

• Audio

  1x 4-ring 3.5mm Headphone Jack

  HD codec that supports up to 24-bit/96KHz audio

• Connectivity

  40x color GPIO

  – 2 x UART

  – 2 x SPI bus

  – 3 x I2C bus

  – 1 x PCM/I2S

  – 1 x SPDIF

  – 2 x PWM

  – 1 x ADC

  – 6 x GPIO

  – 2 x 5V DC power in

  – 2 x 3.3V power pin

• Software

  Debian Linux support

  Android support

• Power Requirements

  – USB C 5V/3A

  – 5V Power applied to GPIO PIN 2 & 4

  – The recommended power source capacity is at least 5V/3A

• Operating Conditions

  Recommended environmental temperature: 0 ~ 50°C

  Rockchip RK3399‑T has a temperature limit of 80°C, beyond which it throttles clock speeds for reliability

  For continuous high-performance use, external cooling methods like heat sinks or fans can maintain maximum clock speed below the 80°C limit

• Dimension

  85 mm x 56 mm

• Compliance Certification

  SRRC / FCC / CE / IC ID / TELEC / RCM / IMDA / NBTC / NTC / OFCA / ICASA
