Interfaces

Especificações Técnicas

• SoC

  Rockchip RK3582

• CPU

  Arm Dual Cortex®‑A76 and Quad Cortex®‑A55 based on Arm®DynamIQ™ configuration

• NPU

  NPU supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration computing power is up to 5TOPs

• RAM

  LPDDR4x

  – 2GB

  – 4GB

  – 8GB

• Multimedia

  H.265 / H.264 multivideo encoder up to 4K@60fps

• Storage

  1x Onboard eMMC

  1x microSD Card Slot

• USB

  1x USB 3.0 Type-A OTG / HOST Port

  1x USB Type-C for Debug

• Ethernet

  2x 2.5 Gigabit Ethernet Ports

• Button

  1x Maskrom Button

  1x User Button

• Power

  1x 5V Only USB Type-C Port

• Operating System

  Radxa OS / OpenWrt / iStoreOS

• Operating Conditions

  Recommended environmental temperature: 0 ~ 50°C

  Radxa E52C has a temperature limit of 80°C, beyond which it throttles clock speeds for reliability

  For continuous high-performance use, external cooling methods like heat sinks or fans can maintain maximum clock speed below the 80°C limit

• Dimension

  70 mm x 70 mm

• Compliance

  FCC / CE
