Interfaces

Especificações Técnicas

• SoC

  Rockchip RK3528A

• CPU

  Quad-core Arm Cortex®-A53 @ 2.0GHz

• GPU

  Arm® Mali™ G450

  – OpenGL® ES1.1, ES2.0

  – OpenVG® 1.1

• RAM

  LPDDR4

  – 1GB

  – 2GB

  – 4GB

• Multimedia

  H.264, H.265 and AVS2 decoder by 4Kx2K@60fps

  H.264 and H.265 encoder by 1920×1080@60fps

• Storage

  1x Onboard eMMC

  1x microSD Card Slot

• USB

  1x USB 2.0 Type-A HOST Port

  1x USB Type-C for Debug and Data

• Ethernet

  2x Gigabit Ethernet Ports

• Button

  1x Maskrom Button

  1x User Button

• Power

  1x 5V Only USB Type-C Port

• Operating System

  Radxa OS / OpenWrt / iStoreOS

• Operating Conditions

  Recommended environmental temperature: 0 ~ 50°C

  Radxa E20C has a temperature limit of 80°C, beyond which it throttles clock speeds for reliability

  For continuous high-performance use, external cooling methods like heat sinks or fans can maintain maximum clock speed below the 80°C limit

• Dimension

  70 mm x 70 mm

• Compliance

  FCC / CE
